Zhejiang Dai's Printing Machine Co., Ltd. is one of the most reliable manufacturers and suppliers of 1450f sheet turning machine in China. If you're going to buy bulk discount 1450f sheet turning machine, welcome to get quotation from our factory. All customized machines are with high quality and competitive price.
Technical Parameter
|
(max.paper size) |
1450mm×1300mm |
|
(min.paper size) |
500mm×450mm |
|
(Paper type) |
corrugated paper |
|
(Flip speed (number of times) |
5-6次/min |
|
total power) |
≈15KW |
|
(machine weight) |
5500Kg |
|
(overall dimension) |
8800mm*3400mm*2900mm |
Installation Structure Diagram
The automatic paper turning machine is a high-speed turning machine integrating mechanical and electrical automation with computer control. It is a supporting product for laminating machines and can be connected with laminating machines from any manufacturer. It automatically stacks laminated paper sheets into neat piles according to the preset quantity. As an integrated automatic device, it combines paper collecting, stacking, intermittent turning and palletizing functions, enabling front-and-back stacking.
This machine effectively prevents cardboard deformation after lamination, reduces labor intensity of manual paper collecting, and is suitable for palletizing and collecting single-face corrugated paper, multi-layer corrugated paper, paperboard and other materials. It features neat stacking, high efficiency, easy operation and convenient maintenance, making it an ideal equipment for small, medium and large packaging plants.
The automatic paper turning machine consists of seven parts:A. Paper separating unit B. First pusher unitC. Turning & lifting unitD. Second pusher unitE. Aligning & stacking unitF. Push plate unitG. Roller output unit
Exploded View A Paper Separating Mechanism
The paper laminated by the laminating machine is fed sheet by sheet into the first pusher frame via the paper separator to form a certain thickness.
Exploded View B First Pushing Mechanism
After the paper separator feeds paper into the first pusher frame to a certain height, the sensor detects it and the first pusher pushes the paper into the turning cage to wait for the next command.
Exploded View C Turning Lifting Mechanism
The paper fed by the first pusher is delivered into the turning cage. Turning and lifting are realized by the lifting motor and servo motor, allowing the paper to enter the next process alternately face up and face down.
Exploded View D Second Pushing Mechanism
The turning and lifting mechanism raises the paper to the top position where a stack of paper stops, then the second pusher feeds the paper into the rear paper collecting and aligning system.
Exploded View E Paper Aligning, Collecting and Stacking Mechanism
At the top of the machine, the paper is pushed onto the paper supporting board by the second pusher. The side patting device driven by the air cylinder pre-aligns the paper. Then the paper supporting board opens, allowing the paper to drop onto the paper receiving table. The paper supporting board performs final paper patting via the air cylinder, and this process repeats twice.
Exploded View F Push Plate Mechanism
The paper pushing mechanism feeds empty pallets into the paper receiving table. After the stack is full, the full paper stack is discharged by the roller conveyor. The push plate then feeds an empty pallet into the paper receiving table, enabling non-stop production and improving efficiency.
Exploded View G Roller Output Mechanism
The roller output mechanism uses powered rollers to discharge the full paper pallet as a whole. A forklift only needs to be positioned between the rollers outside the machine, waiting for the powered rollers to deliver the full paper pallet onto the external receiving rollers, after which the forklift can pull it away. This realizes automated production.
Equipment Display
